VMD03-8521(C)

3MP depth resolution with high accuracy — ideal for diverse applications such as positioning, bin-picking,machine tending, measurement,and inspection.

Parameters

Model

VMD03-8521(C)

Working Distance

0.85 m ~ 2.1 m

FOV(H/V)

51°/41°

Accuracy(Z)

0.085mm@1190mm

Accuracy(XY)

0.6mm@1190 mm

Frame Rate@ Resolution (Depth)

Quality mode:

0.63 fps @ 2048 x 1536

0.63 fps @ 1024 x 768

0.63 fps @ 512 x 384



Standard mode:

0.76 fps @ 2048 x 1536

0.76 fps @ 1024 x 768

0.76 fps @ 512 x 384


Fast mode:

0.99 fps @ 2048 x 1536

0.99 fps @ 1024 x 768

0.99 fps @ 512 x 384

Frame Rate @ Resolution (RGB)


Note:
8521C: RGB supported | Model 8521: No RGB

5 fps @ 2560 x 1920 @ YUYV

7 fps @ 2560 x 1920 @ CSI BAYER12GBRG

9 fps @ 1920 x 1440 @ YUYV

15 fps @ 1280 x 960 @ YUYV

15 fps @ 640 x 480 @ YUYV

Power Supply

DC 24 V ~ 48 V

Power & Trigger Connector

M12 A-Code, 8-pin, male connector

Data Connector

M12 X-Code, 8-pin, female connector

Gigabit Ethernet

Power Consumption

≤ 24 W

Temperature

Operation:0 ℃ ~ 40 ℃

Storage:-10 ℃ ~ 55 ℃

Ingress Protection

IP65

Size

449 mm x 104 mm x 64 mm

Weight

2307 g

Size
