3MP depth resolution with high accuracy — ideal for diverse applications such as positioning, bin-picking,machine tending, measurement,and inspection.
Model
VMD03-1230(C)
Working Distance
1.2 m ~ 3 m
FOV(H/V)
51°/41°
Accuracy(Z)
0.083mm@1200mm
Accuracy(XY)
0.6mm@1200 mm
Frame Rate@ Resolution (Depth)
Quality mode:
0.63 fps @ 2048 x 1536
0.63 fps @ 1024 x 768
0.63 fps @ 512 x 384
Standard mode:
0.76 fps @ 2048 x 1536
0.76 fps @ 1024 x 768
0.76 fps @ 512 x 384
Fast mode:
0.99 fps @ 2048 x 1536
0.99 fps @ 1024 x 768
0.99 fps @ 512 x 384
Frame Rate @ Resolution (RGB)
Note:1230C: RGB supported | Model 1230: No RGB
5 fps @ 2560 x 1920 @ YUYV
7 fps @ 2560 x 1920 @ CSI BAYER12GBRG
9 fps @ 1920 x 1440 @ YUYV
15 fps @ 1280 x 960 @ YUYV
15 fps @ 640 x 480 @ YUYV
Power Supply
DC 24 V ~ 48 V
Power & Trigger Connector
M12 A-Code, 8-pin, male connector
Data Connector
M12 X-Code, 8-pin, female connector
Gigabit Ethernet
Power Consumption
≤ 24 W
Temperature
Operation:0 ℃ ~ 40 ℃
Storage:-10 ℃ ~ 55 ℃
Ingress Protection
IP65
Size
449 mm x 104 mm x 64 mm
Weight
2307 g
