VMD02-4070

3MP depth resolution with high accuracy — ideal for diverse applications such as positioning, bin-picking,machine tending, measurement,and inspection.

Parameters

Model

VMD02-4070

Working Distance

0.4 m ~ 0.7 m

FOV(H/V)

51°/42°

Accuracy(Z)

0.023mm@490mm

Accuracy(XY)

0.25mm@490mm

Frame Rate@ Resolution (Depth)

Quality mode:

0.63 fps @ 2048 x 1536

0.63 fps @ 1024 x 768

0.63 fps @ 512 x 384

Standard mode:

0.76 fps @ 2048 x 1536

0.76 fps @ 1024 x 768

0.76 fps @ 512 x 384

Fast mode:

1.05 fps @ 2048 x 1536

1.05 fps @ 1024 x 768

1.05 fps @ 512 x 384

Frame Rate @ Resolution (RGB)

-

Power Supply

DC 24 V ~ 48 V

Power & Trigger Connector

M12 A-Code, 8-pin, male connector

Data Connector

M12 X-Code, 8-pin, female connector

Gigabit Ethernet

Power Consumption

≤ 24 W

Temperature

Operation:0 ℃ ~ 40 ℃

Storage:-10 ℃ ~ 55 ℃

Ingress Protection

IP65

Size

268 mm x 105 mm x 65 mm

Weight

2080 g

Size
