FM855-E1

Model

FM855-E1

Working Distance

0.4m – 8m

FOV（H/V）

59°/48°

Accuracy(Z)

1.33mm @ 1000mm；2.30mm @ 1500mm

Accuracy(XY)

6.86mm@1000mm；10.29mm@1500mm

Depth Resolution

1280 x 960

RGB Resolution

2560 x 1920

Power Supply

DC 24V ; PoE(IEEE802.3af/at)

Power & Trigger Connector

M12 A-Code, 8-pin, male connector

Data Connector

M12 A-Code, 8-pin, female connector Gigabit Ethernet

Power Consumption

5W ~ 9W

Temperature

Storage：-20℃~55℃; Operation：-10℃~50℃

Ingress Protection

IP65

Size

145mm * 35mm * 90mm

Weight

620 g
